In the first part of this series we set up a Mule app and a Salesforce Connected app for the OAuth JWT bearer token flow.
In this second part, we’ll go through the required steps to set up mTLS between the Mule app and the Salesforce Connected App we created in that first post.
You can also follow this video tutorial from our Mulesoft Ambassador, Stefano Bernardini:
Create a new profile in Salesforce for mTLS
If the Profile you used in Part I of this guide is the definitive one that you’ll use for this mule app skip this step
Go to Setup > Profiles
Click on New Profile
- Pick up an existing profile to clone from and give it a name. We’ll clone the System Administrator profile in this example, just for the purpose of the demonstration. As a best practice, pick up an Integration User Profile or an existing profile associated with the Named Users you’re planning to use from the Mule App.
- Have a look at these posts if you want to know best practices for the Integration user for Mule:
Click Save
Back to the Profile overview page scroll down to the System section and click on System Permissions
Add the Enforce SSL/TLS Mutual Authentication from the list of permissions. If you don’t see this option you need to contact Salesforce to enable the feature.
Assign a user to the new profile. That would be the user (or users) that we’ll use in the Mule app. Depending on your use case it can be a Named User or an Integration User
Go to Setup > Users and click on your selected user
In the User page click on Edit and change the Profile to our newly created profile for mTLS
Click Save
(Optional) Create a Connected App associated with this Profile
Skip this step if you’ll be using the Connected App created in Part I
If not, follow the steps in Part I to create a new Connected App and the configuration of the Mule app to use OAuth JWT as auth flow in the salesforce connector.
Set Up Mutual Authentication Certificate
Go to Setup > Certificate and Key Management and click on the Upload Mutual Authentication Certificate within the Mutual Authentication Certificates section. If you don’t see this section in the Certificate and Key Management page you’ll need to open a support ticket with Salesforce to get this feature enabled in your org.
- Provide a name and a label for your certificate and then add the certificate. Remember that self-signed certificates are not valid for mTLS. In here, we’ll be uploading the certificate with the public key for your user(s) in the Mule App. The corresponding private key we’ll be stored in the mule app.
You must upload a PEM-encoded client certificate. You only need to upload the client certificate itself; do not upload a certificate chain.
Configuration of the Mule App
In this section, we’ll continue with the mule app created in Part I of this guide. Refer to that part if you need to start with a new mule application.
Upload the Key Store to the Mule Project
Go to your Mule app in Anypoint Studio
If you haven’t done it, create a key store that will include your private/public key pair. You can do it as a JKS, PKCS12 or JCEKS. All of them are valid. In this guide we’ll use JKS. You can use any tool such as Key Store Tool.
Right-click on the project name and select Show In > System Explorer. That should open a explorer window at the main folder of our project.
From there, go to resources and upload the jks file of our keystore.
Back to Studio, if you right click again in the name of our project and click Refresh we should see our keystore under the src/main/resources folder.
Set up the Key Store in the Salesforce Configuration Element
Next, from the canvas, go to the Global Elements tab and open the Salesforce Config element.
Go to the Security Tab and select the Edit Inline option in the TLS configuration dropdown (or select global reference if you prefer to set this configuration as a Global Configuration Element).
In this tab, we need to provide the Key Store for the User(s) that will be accessing our Salesforce Connected App via the Salesforce connector in our mule app. The Key store has to contain the private key corresponding to the public key and certificate that we uploaded in our previous step in Salesforce as Mutual Authentication Certificate.
Select the type of Key Store, in this guide is JKS
The path within the app of the keystore. The root path corresponds to the src/main/resources folder in our Mule Project. In our example, we uploaded the key store in that root folder
Provide the password for your keystore
Test the connection
Run the app in Studio
Test the app and verify that your Salesforce query is successful
